Description
Size: 1”, 2”
End Connection: – Threaded
Features:
- Compact Single Union (One Nut) design
- Quarter Turn Hand Operated On/Off Ball Valve.
- Operating Pressure: 16 Bar
- User-Friendly Design Allows Smooth Operation of Handle.
- Industrial, Chemical, turf & agriculture irrigation system application.
- Chemical/corrosion resistant color UV Stabilized.
| Part No | Part Name | Material | QTY. |
|---|---|---|---|
| 1 | Ring | PP | 1 |
| 2 | Bush | PP | 1 |
| 3 | Seal | EPDM | 2 |
| 4 | Ball | PP | 1 |
| 5 | Body | PP | 1 |
| 6 | Shaft | PP | 1 |
| 7 | Shaft-O-Ring | Nitrile | 2 |
| 8 | Main–O-Ring | Nitrile | 1 |
| 9 | Handle | ABS | 1 |
